iGeneTech Bioscience Co., Ltd.
EN

HRD Panel & HRR Panel

Overview
Performance
Ordering Info
Video
Resources

Overview

iGeneTech® has launched HRD Panel and HRR Panel products based on TargetSeq® hybrid capture sequencing technology, relying on MGI and Illumina, two major high-throughput sequencing platforms. Among them, the HRR Panel product includes 39 core HRR (Homologous Recombination Repair) genes, which is used for the detection of gene mutations in the HRR pathway. The HRD Panel product covers 37,000 SNP loci, which is used to calculate three genomic scar indicators: LOH (Loss of Heterozygosity), TAI (Telomeric Allelic Imbalance), and LST (Large-Scale Transition), derive the HRD score, and evaluate HRD (Homologous Recombination Deficiency) status.
Meanwhile, iGeneTech® HRD & HRR Panel V2 enables the combined use of the HRD Panel and HRR Panel, which can simultaneously evaluate HRD status and detect HRR gene mutations. It can be applied to scenarios such as risk prediction, medication guidance, molecular typing, and prognostic monitoring.


HRD-Panel-HRR-Panel-1
HRD-Panel-HRR-Panel-2
HRD-Panel-HRR-Panel-3

Product Parameter

Panel Number

TargetSeq® HRD Panel: T974V1hg38

TargetSeq® HRR Panel: T975V1hg38

TargetSeq® HRR & HRD Panel v2.0: T976V1hg38

Technical Platform
TargetSeq® Hybridization Capture Sequencing
Coverage Size

TargetSeq® HRD Panel: 3.9 Mb

TargetSeq® HRR Panel: 177.9 kb

TargetSeq® HRR & HRD Panel v2.0: 4.1 Mb

Reference Database
dbSNP、1000Genomes、Refseq
Reference Genome

GRCh38 (hg38)

Coverage

•TargetSeq® HRD Panel: 37,000 HRD-related SNPs

•TargetSeq® HRR Panel: Exons and splicing regions of 39 core HRR genes

•TargetSeq® HRD & HRR Panel V2: 37,000 HRD-related SNPs and Exons and splicing regions of 39 core HRR genes

Storage

-20℃±5℃

Sequence Platform
Illumina / MGI
Recommend Sequencing Read Length
PE150
Recommend Sequencing Data Size and Depth

TargetSeq® HRD Panel:6 Gb / 500×

TargetSeq® HRR Panel:0.5Gb / 1,000×

TargetSeq® HRR & HRD Panel v2.0:4 Gb / HRD 300×, HRR 1,200×


Request a Consultation

Advantages

  • HRD Panel: 37,000 SNPs designed based on Chinese population genetic background and efficacy databases, effectively covering the whole genome.
  • HRR Panel: 39 core HRR pathway genes selected based on latest NCCN guidelines, oncology clinical trials and top scientific research.
  • HRD & HRR Panel V2: Optimized probe ratio (HRD:HRR depth 1:4), meeting co-detection needs and saving data volume.
  • Compatibility & customization: Compatible with other iGeneTech® Panels; flexible design of supplementary regions per customer needs for customized exclusive HRD detection Panels.


Request a Consultation

Performance

Capture Data


Figure 1. Capture Performance Test of HRR Panel. Using gDNA standards, with TargetSeq One® Hyb & Wash Kit v3.0 hybrid capture system, sequenced on Illumina NovaSeq 6000 (PE150).


Figure 2. Capture Performance Test of HRD Panel.Using gDNA kits to construct libraries, with TargetSeq One® Hyb & Wash Kit v3.0 hybrid capture system, sequenced on Illumina NovaSeq 6000 (PE150).


Figure 3. Capture Performance Test of HRD & HRR Panel V2.Using gDNA kits to construct libraries, with TargetSeq One® Hyb & Wash Kit v3.0 hybrid capture system, sequenced on Illumina NovaSeq 6000 (PE150).


Figure 4. 1:4 Depth Difference Test of HRD & HRR Panel V2.Using gDNA kits to construct libraries, with TargetSeq One® Hyb & Wash Kit v3.0 hybrid capture system, sequenced on Illumina NovaSeq 6000 (PE150).


Accurate analysis of HRD Score

Table 1. HRD Standard Test Results

Sample

LOH

TAI

LST

HRD-sum

Result(≥43)

Positive-High Ref

18

32

40

90

HRD-H

HRD-P9-T-Repeat 1

17

23

26

66

HRD-H

HRD-P9-T-Repeat 2

18

24

31

73

HRD-H

Negative-Low Ref

5

10

10

25

HRD-L

HRD-P13-T-Repeat 1

5

12

10

27

HRD-L

HRD-P13-T-Repeat 2

5

11

10

26

HRD-L

Critical Value-Median Ref

16

20

9

45

HRD-C

HRD-P15-T-Repeat 1

18

19

13

50

HRD-H

HRD-P15-T-Repeat 2

16

21

15

52

HRD-H

Note: Three sets of Kebai HRD standards (HRD-P9; HRD-P13; HRD-P15) were tested. Combined with iGeneTech's HRD analysis workflow and thresholds, HRD scores were calculated to determine HRD status.


Learn More About HRD Panel & HRR Panel

Ordering Info

HRD Panel & HRR Panel
Product NamePanel NumberSetCat. No
TargetSeq® HRD Panel

T974V1hg38

24 rxn

PH2000975

96 rxn

PH2000972

TargetSeq® HRR Panel

T975V1hg38

24 rxn

PH2003715

96 rxn

PH2003712

TargetSeq® HRR & HRD Panel v2.0

T976V1hg38

24 rxn

PH2003805

96 rxn

PH2003802


Resources

Demo DataSet
  • TargetSeq® HRR Panel (T975V1hg38) demo data
    TargetSeq® HRR Panel (T975V1hg38) demo data
  • TargetSeq® HRD Panel (T974V1hg38) demo data
    TargetSeq® HRD Panel (T974V1hg38) demo data
  • TargetSeq® HRD & HRR Panel v2 (T976V1hg38) demo data
    TargetSeq® HRD & HRR Panel v2 (T976V1hg38) demo data
bed File
  • TargetSeq® HRR Panel (T975V1hg38) bed file
    TargetSeq® HRR Panel (T975V1hg38) bed file
  • TargetSeq® HRD Panel (T974V1hg38) bed file
    TargetSeq® HRD Panel (T974V1hg38) bed file
  • TargetSeq® HRD & HRR Panel v2 (T976V1hg38) bed file
    TargetSeq® HRD & HRR Panel v2 (T976V1hg38) bed file
Flyer
